With a digital camera program, image processing software tools, lighting technology, optics, mechanical constructions and network technology KAPPA provides complete solutions. The fully automated image processing systems for 100 % QA control are designed for perfect integration and customer-specific configuration. The visualization systems for the control of production processes and machine settings are convincing even under difficult environmental conditions. They can also be used for remote maintenance. Our camera systems are perfect for microscopes, endoscopes and macro optics. They are used as standalone-systems for incoming goods inspection and for industrial endoscopy applications.

Packing Automatic Quality inspection

KAPPA Machine Vision for Paper Bags :-
Automatic Quality inspection for block bottom bags is performed by the KAPPA image processing system. Dimensional accuracy and geometry are controlled at high speed.



Centricity inspection of membrane discs

KAPPA Machine Vision for Sartorius :-

The KAPPA image processing system checks the membrane discs position on sterile filters. Not centrically welded membranes are automatically selected (rejectable).



Inspection System for Cylinder Running Surfaces

Image Processing System for Engine Industry :-
Image Processing System for Engine Industry KAPPA provides a special system for surface measuring of honed cylinder running surfaces. It visualizes and measures precisely the typical honed structure and documents the results.



Optical Weld Seam Inspection

Automated QA System for General Motors - OPEL :-
The weld seams of automobile gears welded with a laser or with an electronic beam are precisely measured. The KAPPA image processing software KIB Xero evaluates the images in a fraction of a second.



QA System for Plastics Processing

Inspection System for Toha Kunststofftechnik GmbH :-
The KAPPA complete system inspects plastic goods with regard to surface purity and black spot detection (from a size of 50 mm). With the identification of the source of defect the output can be optimized in view of quality and quantity.



Visual PCB Inspection

QA System for PCB Production at Sartorius :-
The KAPPA QA system inspects the presence and correct position of connectors on printed circuit boards.



Video Surveillance of the Manufacturing Process

Observation at Machine Tool Manufacturer Heckert Werkzeugmaschinen GmbH :-
Direct visual observation of the machining process in large machining centers is impossible. The KAPPA DVM module surveys the process and informs the operator via monitor about failures. With the image transmission via network the technicians at the face can be supported with remote diagnosis.



Optical Measurement of Clockworks

Optical QA System for Swiss Watch Manufacturer:-
KAPPA provides a system solution with non-contact optical measurement for the inspection of smallest parts of the clockwork.
